Pure HT: New entry level range, the Harman Kardon AVR70 released last 3rd quarter of 2012. This will fit the low budget receivers.
The Harman Kardon AVR70
A premium home theater experience is within your reach. The Harman Kardon® AVR 70 delivers a fully immersive, 5.1-channel, surround-sound experience while playing high-definition sources at maximum quality. HDMI® technology with 3D and Audio Return Channel connections allows you to watch your favorite films as if you were in a movie theater. Dolby® TrueHD and DTS-HD Master Audio™ decoding technology deliver the most realistic sound possible, no matter what your home theater setup is like. Enjoy movies at home as never before. Experience the Harman Kardon AVR 70.
The home theater of your dreams is ready and waiting for you. The Harman Kardon® AVR 70 audio/video receiver takes the well-earned Harman Kardon reputation for outstanding sound quality and makes it widely accessible. Three HDMI® inputs give you versatile connectivity with a variety of media. Thanks to the HDMI Audio Return Channel, these inputs even route the audio from a smart TV’s sound system through the superior Harman Kardon system for greater audio clarity and power.
Five-channel sound with 75 watts per channel (plus a subwoofer output for a full 5.1-channel system) creates a completely immersive sound environment in your home theater, no matter how you choose to configure it. Dolby® TrueHD and DTS-HD Master Audio™ decoding technologies allow you to enjoy all the movie soundtracks, music and video games that you want to play, with realism that makes you feel as though you are in the center of the action. Take your home theater to the next level. Experience the Harman Kardon AVR 70.
Awards
Nothing so far
Reviews
Nothing so far
Specifications
| Model Name | Harman Kardon AVR70 |
| Amplifier Section | |
| Channel | 5.1 |
| Rated Output Power | |
| Front | 75 watts per channel two channels driven THD |
| @ 6ohms, 1 kHz,<1.0% | |
| Center | 75 watts per channel two channels driven THD |
| @ 6ohms, 1 kHz,<1.0% | |
| Surround | 75 watts per channel two channels driven THD |
| @ 6ohms, 1 kHz,<1.0% | |
Surround Sound Processing |
|
| CINEMA DSP | No |
| DSP Programs | No |
| Compressed Music Enhancer | No |
| Virtual Presence Speaker | No |
| Dialogue Lift | No |
| SILENT CINEMA / Virtual CINEMA DSP | No |
| Dolby TrueHD | Yes |
| Dolby Digital Plus | Yes |
| Dolby Pro Logic IIx | Yes |
| DTS-HD Master Audio | Yes |
| Dialog Level Adjustment | Yes |
| Logic 7 | No |
| Headphone Mode | No |
| Audio Features | |
| Pure Direct | Yes |
| MIC Calibration | Yes EzSet/EQ Mic |
| Adaptive DRC (Dynamic Range Control) | No |
| Initial Volume & Maximum Volume Setting | Yes |
| Bi-amp capability | No |
| Audio Delay | yes |
| 192kHz/24-bit DACs for all channels | No |
| High-resolution Music Enhancer | No |
| Video Features | |
| HDMI 3D passthrough | Yes |
| HDMI Audio Return Channel | Yes |
| Component upconversion | No |
| HDMI upscaling | No |
| Video adjustment | Yes |
| Deep Color/x.v.Color/24Hz Refresh Rate /Auto Lip-Sync | Yes |
| 4K Pass-through & 4K Upscaling | No |
| Extensive Connection | |
| HDMI Input/Output | 3 in / 1 Out |
| HDMI CEC | No |
| USB Input | Yes |
| Network Port | Yes |
| Front AV Input | Yes - USB/Composite/Analog/Headphone |
| Digital Audio Input/Output: Optical | 2 in / 0 out |
| Digital Audio Input/Output: Coaxial | 1 in / 0 out |
| Analog Audio Input/Output | 4 in / 2 out |
| Phono Input | No |
| Component Video Input/Output | No |
| S-Video Input/Output | No |
| Composite Video Input/Output | 2 in / 2out |
| Multi-Channel Input | No |
| Preout | Subwoofer |
| Headphone Output | Yes |
| Connectivity | |
| AirPlay | No |
| Bluetooth | Optional Adapter |
| Network | No |
| Tuner Section | |
| FM/AM Tuner | Yes |
| HD Radio Compatibility | No |
| User Interface | |
| On-screen display | Yes |
| App Control | No |
| Web Browser Control | No |
| Remote Control Unit | Yes |
| Control 4 Certified | No |
| Zone Control | |
| Zone HDMI | No |
| Zone 2 Audio Output | No |
| Zone 3 Audio Output | No |
| Zone 4 Audio Output | No |
| Powered Zone | No |
| Zone Video Output | No |
| Zone GUI | No |
| RS-232C Interface | Yes |
| +12V Trigger Output | No |
| Remote (IR) Input/Output | No |
| Party Mode | No |
| General | |
| Power Consumption | 280w |
| Dimensions (W x H x D) | 440x125x330mm (17-5/16 x 4-5/16 x 13inch) |
| Weight | 9.1kg (20lb) |
